** Image may not exactly match product **
Broadcom 9300-16e 16-Port 12Gb/s SAS+SATA to PCI Express Host Bus Adapter New

Broadcom 9300-16e 16-Port 12Gb/s SAS+SATA to PCI Express Host Bus Adapter New

Part Number: 9300-16E
BRAND: BROADCOM | More CONTROLLERS from BROADCOM
$330.00
Capacity: 16PORT

Quantity :
 5% Discount on Checkout
    Extra 1% Discount on MobileApp
| Product Overview

BROADCOM 9300-16E 16-port 12gb/s Sas+sata To Pci Express Host Bus Adapter

Key Features :

Io Controller: Two, Sas 3008/ Fusion Mpt 2.5

Storage Connectivity, Data Transfer Rates: 16 Ports, 12gb/s Sas 3.0 Compliant

Sas Bandwidth: Half Duplex (x4 Wide Bus) 4800 Mb/s

Port Configurations

  • 16 X1 Ports (individual Drives)
  • 4 X4 Wide Ports
  • X8 Wide Ports

    Host Bus: X8 Lane, Pcie 3.0 Compliant

    Pci Data Burst Transfer Rates : Half Duplex X8, Pcie, 8000 Mb/s

    Physical Dimensions : .4” X 6.6”

    Connectors: Four (x4) Mini-sas Hd External Connector (sff8644)

    Cable Support: Passive Copper, Active Copper

    Operating Voltage: +12v +/-8%, 3.3v +/-9%

    Pci Power (nominal): 28.6w

    Device Support: 1024 Non-raid Sata/sata Devices Per Controller

    Environmental:
  • Operating: 0oc To 55oc
  • Storage: -45°c To 105°c
  • 5 To 90% Non-condensing
  • Airflow: 200 Lfm
  • Mtbf >1,500,000 Hours

    Os Support Microsoft Windows, Linux (suse , Red Hat), Solaris, Vmware, Freebsd

    Condition: New Factory Sealed.
    Availability: In Stock.
    Our Warranty: 90 Days
