Detail overview

BROADCOM SAS9400-8E 12gb/s Sas/sata/nvme Tri-mode Pcie Hba.

Overview

Designed For Large-scale External Storage Enclosures, The 9400-8e Tri-mode Storage Adapter Is Ideal For Increased Connectivity And Maximum Performance For Data Center Flexibility.

with Increased Bandwidth And Iops Performance Compared To Previous Generations, The 9400-8e Adapter Delivers The Performance And Scalability Needed By Critical Applications.

• Connects Up To 1024 Sas/sata Devices.

• Provides Maximum Connectivity And Performance For High-end Servers And Applications.

• Support Critical Applications With The Bandwidth Of Pcie® 3.1 Connectivity.

• Ideal For Connecting Large-scale External Storage Enclosures.

Specifications

Host Bus Type X8 Lane Pci Express® 3.1

Devices Supported Sas/sata: 1024

External Connectors Connectors 2 Mini-sas Hd Sff8644

Operating Temperature 10° To 55° C

Operating Voltage +12v +/-8%, 3.3v +/-9%

Os Support Microsoft Windows, Linux, Vmware.

Pci Power Typical: 9.48w

Cable Support Passive Copper, Active Copper, Active Optical

I/o Controller Sas3408

Mtbf > 4,500,000 Hours At 40° C

Operating Humidity 5% To 90% Non-condensing

Data Transfer Rates 12gb/s Sas-3 Compliant

Physical Dimensions 6.600 X 2.712

Condition : New Factory Sealed
Availability : In Stock.
Our Warranty : 30 Days.
