Detail overview

BROADCOM SAS9560-16I Megaraid 12gb/s Sas/sata Pcie Gen 4.0(nvme) Tri-mode Raid Controller.

Technical Information:

Port Count: 16 Internal

Connectors: Two X8 Sff-8654

Host Interface: X8 Pcie Gen 4.0

Storage Interface: 12gb/s Sas, 6gb/s Sata, Gen 4.0 Pcie (nvme)

Raid On Chip Controller (roc): Sas3916

Max Devices Per Controller: Sas/sata: 240nvme: 24

Cache Size: 8 Gb

Cache Protection: Cachevault, Cvpm05

Raid Features:
• Raid Levels 0, 1, 5, And 6
• Raid Spans 10, 50, And 60
• Jbod Mode With R0/1/10 And Jbod For Sds Environments
• Online Capacity Expansion (oce)
• Auto Resume After Loss Of System Power During Array Rebuild Or Oce
• Single Controller Multipathing
• Load Balancing
• Configurable Stripe Size Up To 1 Mb
• Fast Initialization For Quick Array Setup
• Check Consistency For Background Data Integrity
• Ssd Support With Ssd Guard™ Technology
• Patrol Read For Media Scanning And Repairing
• 64 Virtual Drive Support

Management Utilities:
• Lsi Storage Authority (lsa)
• Storcli (command-line Interface)
• Hii (uefi Human Interface Infrastructure)

Os Support: Microsoft Windows, Vmware Vsphere/esxi, Red Hat Enterprise Linux, Suse Linux, Ubuntu Linux, Citrix Xenserver, Centos Linux, Debian Linux, Oracle Enterprise Linux, Fedora, Freebsd.see WWW.BROADCOM.COM/SUPPORT/DOWNLOAD-SEARCH For Details On Versions.

Dimensions: 6.127 In. × 2.712 In. (155.65 Mm × 68.90 Mm)

Typical Power: 13.21w

Operating Voltage: 12v ±8%, 3.3v ±9%

Condition : New Factory Sealed.
Availability : In Stock.
Our Warranty : 30 Days
