Detail overview

The Catalyst 9300 Series Is An Advanced Stackable Switching Platform. These Network Switches Are Built For Security, Iot, And The Cloud.

specifications
- Description : CISCO Catalyst 9300 - Network Advantage - Switch - 48 Ports -
Managed - Rack-mountable
- Device Type : Switch - 48 Ports - L3 - Managed - Stackable
- Enclosure Type : Rack-mountable 1u
- Subtype : Gigabit Ethernet
- Ports : 48 X 100/1000/2500/5000/10000 (upoe)
- Power Over Ethernet (poe) Upoe
performance
- Switching Capacity: 640 Gbps
- Stacking Bandwidth: 480 Gbps
- Forwarding Rate : 190.48 Mpps
capacity
- Ipv4 Routing Table Entries: 32000
- Ipv6 Routing Table Entries: 16000
- Flexible Netflow Entries : 64000
- Vlan Ids : 4000
- Switched Virtual Interfaces (svis): 2000
- Mac Address Table Size : 32000 Entries
- Jumbo Frame Support : 9198 Bytes
- Routing Protocol : Ospf, Is-is, Rip-1, Rip-2, Bgp, Eigrp, Hsrp, Igmp, Vrrp,
Pim-sm, Ospfv3, Pim-ssm, Msdp, Policy-based Routing (pbr),
Ripng

- Remote Management Protocol : Snmp 1, Rmon 1, Rmon 2, Snmp 3, Snmp 2c, Cli,
Netconf, Restconf

- Power : Ac 120/230 V (50 - 60 Hz)
- Power Redundancy : Optional
- Dimensions (wxdxh) 17.5 In X 17.5 In X 1.7 In
- Weight : 16.73 Lbs

Condition : New Factory Sealed.
Availability : In Stock.
Our Warranty : 30 Days.
