Detail overview

HPE JL429A Aruba 3810m 48g Poe+ 4sfp+ 1x 1050w Psu Switch 48 Ports Managed Rack-mountable Switch

Key Features :

Device Type : Switch 48 Ports L3 Managed Stackable

Enclosure Type : Rack-mountable 1u

Subtype : Gigabit Ethernet

Ports : 48 X 10/100/1000 (poe+)

Power Over Ethernet (poe) : (poe+)

Performance : Latency (1000base-t): 2.8 Latency (10 Gbps): 1.8 Latency (40 Gbps): 1.5us Throughput (64-byte Packet Size): Up To 190.5 Mpps Routing/switching Capacity: 320 Gbps Switching Fabric Bandwidth: 338 Gbps

Capacity : Ipv4 Routing Table Entries: 10000 Ipv6 Routing Table Entries: 5000

Mac Address Table Size : 64k Entries

Jumbo Frame Support : Yes

Routing Protocol : Ospf, Rip, Rip-1, Rip-2, Bgp, Vrrp, Ospfv2, Ospfv3, Static Ipv4 Routing, Static Ipv6 Routing, Ripng, Mld, Bidirectional Forwarding Detection (bfd)

Remote Management Protocol : Snmp 1, Rmon 1, Rmon 2, Rmon 3, Rmon 9, Rmon, Telnet, Snmp 3, Snmp 2c, Http, Ssh, Ssh-2, Cli, Xrmon

Encryption Algorithm : Ssl

Authentication Method : Radius, Tacacs+, Secure Shell V.2 (ssh2)

Features : Arp Support, Spanning Tree Protocol (stp) Support, Per-vlan Spanning Tree (pvst), Access Control List (acl) Support, Quality Of Service (qos), Device Link Detection Protocol (dldp) Support, Uni-directional Link Detection (udld), Management Information Base (mib), Dynamic Vlan Support (gvrp), Multiple Vlan Registration Protocol (mvrp), Class Of Service (cos), Sflow V5, Type Of Service (tos), Openflow Support, Internet Control Message Protocol (icmp)

Compliant Standards : Ieee 802.3, Ieee 802.3u, Ieee 802.3ab, Ieee 802.1p, Ieee 802.3af, Ieee 802.3ad (lacp), Ieee 802.1x, Ieee 802.1s, Ieee 802.1v, Ieee 802.11n, Ieee 802.1ab (lldp), Ieee 802.3at

Processor : 2

Ram : 6 Gb Ddr3 Sdram

Flash Memory : 1 Gb

Expansion / Connectivity :
Interfaces :

48 X 1000base-t - Rj-45 - Poe+

1 X Serial (console) - Rj-45 - Management

1 X Management - Rj-45

1 X - Rj-45

1 X Micro-usb - Type B

Expansion Slots :

1 (total) / 1 (free) X Expansion Slot

1 (total) / 1 (free) X Stacking Module Slot

Power :

Power Device : Internal Power Supply Hot-plug

Installed Qty : 1 (installed) / 2 (max)

Power Redundancy : Yes

Power Redundancy Scheme : 1+1 (with Optional Power Supply)

Power Provided : 1050 Watt

Voltage Required : Dc 54 V

Energy Star Qualified : Yes

Condition : New Retail Factory Sealed.
Availability : In Stock.
Manufacturer Warranty : Limited Lifetime.
Our Warranty : 30 Days.
